> CA-2103SET P Car alarm set CA-2103, CA-550, JA-185P and PLV-JA85PG
CA-2103SET P Auto alarm set CA-2103, CA-550, JA-185P i PLV-JA85PG View larger

CA-2103SET P Car alarm set CA-2103, CA-550, JA-185P and PLV-JA85PG

CA-2103SET P

New product

JABLOTRON ALARMS S.A.

The set includes the CA-2103 car alarm including full entry protection (doors, engine cover, hood), the CA-550 tilt sensor that detects any car movement including vehicle towing and the JA-185P wireless PIR motion detector for interior protection. An additional gray plastic cover for the interior in different colors is included.

More details

More info

The set includes the CA-2103 car alarm including full entry protection (doors, engine cover, hood), the CA-550 tilt sensor that detects any car movement including vehicle towing and the JA-185P wireless PIR motion detector for interior protection. An additional gray plastic cover for the interior in different colors is included.

Technical specifications
power supply 12/24 V DC (8 – 32 V)
average current consumption max. 20 mA
peak consumption (during communication) 1 A
GSM module operating range E-GSM/GPRS 850 / 900 / 1800 / 1900MHz
max. transmitter output power 2 W for GSM 850/900
1 W for GSM 1800/1900
remote control receiver frequency 868.1 MHz, GFSK, e.r.p. <25 mW
operating temperature range -20 °C to +85 °C
SIR output switching supply voltage, max. load 1.3 A
immobilization circuit 8 A continuous, up to 12 A short-term
output signals for central locking control max. 200 mA, switching to GND
impulse length for central locking 0.5 s or 4 s or possibly 60 s (optional)
in accordance with ECE regulation no. 116
safety EN 62368-1
EMC ECE no. 116, ČSN ETSI EN 301 489-1, -3, -7
radio spectrum ETSI EN 301 511, ČSN ETSI EN 300 220-2
can be used according to ERC/DEC98(20,21), ECC/DEC/(04)06, ERC/DEC/(97)02, ECC/DEC/(06)01, VO-R/10 (ERC/REC 70-03)
