JA-120E-WH Bus outdoor RFID / NFC reader - white

JA-120E-WH

New product

JABLOTRON ALARMS S.A.

JA-120E-WH is a BUS outdoor RFID/MIFARE card reader in white. It supports 125 kHz RFID and 13.56 MHz MIFARE (MIFARE Classic) and features a scratch‑resistant synthetic tempered‑glass front with IP55 protection.

More details

More info

JA-120E-WH is a BUS outdoor access module designed for seamless integration with JABLOTRON 100 / 100+ systems. The reader provides dual‑media reading: 125 kHz RFID and 13.56 MHz MIFARE (MIFARE Classic), allowing compatibility with a broad range of cards and tokens.

The front panel is made of synthetic tempered glass to improve scratch resistance and preserve the device appearance under frequent use. The housing is intended for general outdoor installation and carries an IP55 ingress protection rating.

Power is supplied via the alarm control panel BUS. The device can be enrolled into the system using the F-Link configuration tool or by entering the device serial number, depending on the panel setup procedure.

Typical applications include access control for residential and commercial entrances, token/card‑based entry management and integration with alarm system features. The compact dimensions and low profile make the reader suitable for visible external mounting without being obtrusive.

Technical specifications

  • Power supply: from control panel (BUS)
  • Quiescent (backup) current: 45 mA; Maximum current: 95 mA
  • RFID frequency: 125 kHz
  • MIFARE frequency: 13.56 MHz (MIFARE Classic)
  • Environment: outdoor general
  • Ingress Protection: IP55
  • Operating temperature: -25 °C to +70 °C
  • Dimensions: 96 × 67 × 13,5 mm; Weight: 140 g
  • Connection: BUS to alarm control panel

Ensure correct BUS wiring and follow the installation instructions to maintain IP55 sealing. The reader is intended for standard outdoor conditions; avoid locations with excessive mechanical impact or direct water jets.
